Product Description
This 12kg/m rebuild kit is specifically for the Nismo LSD unit part numbers 38420-RS650 (10mm ring gear bolts) & 38420-RS660 (12mm ring gear bolts)
It can also be used to upgrade the 8kg/m LSD units, which used the (NLA) 3843S-RS650 rebuild kit that has different disc stack quantities
This kit contains:
2- 1.75mm friction plates 38432-N3210 (flat with external ears)
4- 1.75mm friction discs 38433-N3210 (flat with internal ears)
1- 1.85mm friction disc 38433-N3211 (flat with internal ears)
4- 1.75mm spring plates 38435-N3210 (curved with external ears)
2- 1.75mm spring discs 38436-N3210 (curved with internal ears)
2- side washers 38437-_____
3- case screws 38434-N3210
Some components of this kit can be used to rebuild other R200 LSD units such as the OE CLSD in the 87.5-89 Z31 300ZX Turbo
or the earlier Nismo LSD units 38420-RS500, RS520, RS580, RS581, RS585, RS586
but the disc stack counts are different.
More info is still being gathered on this subject
3843S-RS651 3843SRS651
3843S-RS650
